Q-san bobbin former non-metal Kapton Kap(J)
Base Material: Kapton (J)
Thickness Range: 0.030 - 0.125mm
Coated Varnish: SV
Heat Resistance: Max. 250
Q-san bobbin former non-metal Kapton Kap(C)
Base Material: Kapton (C)
Thickness Range: 0.050 - 0.150mm
Coated Varnish: SV
Heat Resistance: Max. 220
Q-san bobbin former non-metal Black-Kapton MTB-T
Base Material: Black-Kapton
Thickness Range: 0.125mm
Coated Varnish: SV
Heat Resistance: Max. 250
Q-san bobbin former non-metal Glass Fiber TIL
Base Material: Glass Fiber
Thickness Range: 0.075 - 0.165mm
Coated Varnish: SV
Heat Resistance: Max. 250
Q-san bobbin former non-metal Nomax NSV
Base Material: Nomax
Thickness Range: 0.050 - 0.130mm
Coated Varnish: SV
Heat Resistance: Max. 250
Q-san bobbin former non-metal Nomax NL
Base Material: Nomax
Thickness Range: 0.050 - 0.130mm
Coated Varnish: Lock
Heat Resistance: Max. 200
Q-san bobbin former non-metal Kraft Paper KSV
Base Material: Kraft Paper
Thickness Range: 0.030 - 0.130mm
Coated Varnish: SV
Heat Resistance: Max. 180
Q-san bobbin former non-metal Kraft Paper KL
Base Material: Kraft Paper
Thickness Range: 0.030 - 0.130mm
Coated Varnish: Lock
Heat Resistance: Max. 150
Q-san bobbin former non-metal Uni-Sheet SIL(BT)
Base Material: Uni-Sheet
Thickness Range: 0.080 - 0.125mm
Coated Varnish: SV
Heat Resistance: Max. 250
*Color variation apply
